ITEM # : MT002

Machine Make : Mitsui Seiki, Japan
Machine Type : CNC Vertical Jig Boring Machine / Jig Borer
Model : 6CNII
Controller : Fanuc 15M
ATC postions : 20

Table longitudinal travel (x-axis) : 1,020 mm
Saddle table transversal travel (y-axis) : 760 mm
Quill vertical travel (z-axis) : 300 mm
Cross rail vertical travel (w-axes) : 750 mm
Distance between columns : 1,120 mm
Table surface : 1,280 mm x 960 mm
Table load : 1,200 kg
Spindle taper : BT45
